Products > C&I Battery Storage > HZEB-ESS100P-200 > HZEB-ESS100P-200

HZEB-ESS100P-200

The HZEB-ESS100P-200 (100kW PCS, 200kWh battery) is an all-in-one outdoor energy storage system with 6000 cycles, IP65 protection, and parallel operation—ideal for commercial/industrial reliable power.

Dawnice - Leading Global Energy Storage Battery Manufacturer & Innovator

Contact

Document

Features

Ground Mounted

Compact design enables flexible installation

Smart Energy

Real-time monitoring and intelligent control

Safety

Multi-protection from self developed BMS

Intelligent Cooling

Smart thermal system maintains optimal performance in allclimates.

Efficient Power Cost

Long cycle life and superior performance

Parameter

PERFORMANCE SPECIFICATIONS

MECHANICAL SPECIFICATIONS

SECURITY AND CERTIFICATION

ENVIRONMENTAL SPECIFICATIONS

PERFORMANCE SPECIFICATIONS

Model

HZEB-ESS100P-200

Product Name

100kW PCS 200kWh Battery Storage System

Nominal Voltage

716.8V

Cell model/Configuration

3.2V 280Ah/224S1P 1 cluster

Capacity(Ah)

280Ah

Rated Energy(kWh)

200.7kWh

Max.Charge/Discharge Current(A)

167A

Voltage Range(V)

627.2~806.4V

Scalability

Scalable via parallel cabinets (typical configurations up to 4–16 units depending on PCS)

Communication

Modbus RTU/Modbus TCP

Cycle Life

≥6000 Cycles@25°C, 80%DOD

MECHANICAL SPECIFICATIONS

Weight(kg)

2500kg

Dimension(L/W/H)(mm)

1500*1330*2185mm

Installation Mode

Ground Mounnted

IP Grade

IP54

SECURITY AND CERTIFICATION

Safety(Pack)

UN38.3.MSDS

Safety(Cell)

UN38.3.MSDS,IEC62619,CE,UL1973,UL2054

Protection

BMS and Breaker

ENVIRONMENTAL SPECIFICATIONS

Operating Temperature(°C)

Charge 0°C~50°C; Discharge -10°C~-50°C

Altitude(m)

s2000m

Humidity

<90%(Non-condensing)
